Asustor AS5404TUmme SadiaMarch 5, 2025March 5, 2025

Asustor AS5404T

  • 4 Bay NAS
  • Intel N5105 2.0GHz (Quad-Core) Processor
  • Memory: 4GB DDR4 (Expandable Max. 16GB)
  • ADM 4.1 Onwards
  • 4 x SATA3 6Gb/s; 3.5″/2.5” HDD/SSD
  • 4 x M.2 SSD Drive Slots
  • Maximum Drive Bays with Expansion Unit: 16
  • RAID Type: Single disk, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
  • 3 x USB 3.2 Gen 2 (10Gbps)
  • 1 x HDMI 2.0b
  • 2 x 2.5 Gigabit Ethernet (2.5G/1G/100M)
  • User Quota
  • AES 256-Bit Encryption
  • Maximum Number of Users: 4096
  • Maximum Number of Concurrent Connections: 512
  • Supports Windows Active Directory
  • 2.5 GbE Supports Wake-on-LAN (WOL)
  • 2.5 GbE Supports Wake-on-WAN (WOW)
  • Up to 44 channels in 720p on single live view display
  • Maximum IP Cam 44 (4 Free Camera Licenses; Additional Licenses to be Purchased)
Categories: , ,

Hardware Specifications
CPU Model Intel Celeron
CPU Architecture x64 64-bit
CPU Frequency Quad-Core
AES-NI hardware encryption engine integrated
Memory 4GB SO-DIMM DDR4 Compatibility
Memory Module Pre-installed 4GB (1x 4GB)
Total Memory Slots 2
Memory Expandable up to 8GB (2x 4GB)

  • Support mixed capacity
Flash Memory 4GB eMMC
Drive Bays 4
Compatible Drive Type Compatibility
  • 3.5″ SATA HDD
  • 2.5″ SATA HDD
  • 2.5″ SATA SSD
Maximum Drive Bays with Expansion Unit 16
Supports Hot Swappable Drives
Expansion 3x USB 3.2 Gen 1
Network 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
Multimedia Output 1x HDMI 2.0a
System Fan 1x 120mm
Infrared Receiver
Power Supply Unit / Adapter 90W x1
Input Power Voltage 100V to 240V AC
Certification FCC, CE, VCCI, BSMI, C-TICK
Warranty 3 Years
Power Consumption 27 W (Operation);
12.6 W (Disk Hibernation);
1.4 W (Sleep Mode)
Noise Level 19.7dB (HDD idle)
Operation Temperature 0°C~40°C (32°F~104°F)
Humidity 5% to 95% RH
Size 170(H) x 174(W) x 230(D) mm
Weight 2.2 kg / 4.85 lbs Package Contents
