SIP 2601E BlackUmme SadiaDecember 5, 2025

SIP 2601E Black

  • 2 SIP account, 2 lines
  • Network Equipment Type IP
  • Model Name/Number GRP 2601
  • Brand Grand stream
  • Color Black
Categories: ,
      • Protocols/Standards
      • SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, HTTP/HTTPS, ARP, ICMP, DNS(A
      • record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED,
      • LDAP, TR-069, SNMP, 802.1X, TLS, SRTP, IPv6
      • Network Interfaces Dual switched auto-negotiation 10/100 Mbps Ethernet ports, integrated PoE
      • (GRP2601P only)
      • Wi-Fi GRP2601W, Single frequency, 2.4 GHz, 802.11 b/g/n/ax (2.4G only)
      • Graphic Display 132 x 48 (2.41’’) LCD display
      • Feature Keys
      • 4 XML programmable context sensitive soft keys, 5 (navigation, menu) keys. 8
      • dedicated function keys for: MESSAGE(with LED indicator), TRANSFER,HEADSET,
      • MUTE, SEND/REDIAL, SPEAKERPHONE, VOL+, VOLVoice Codecs and Capabilities
      • Support for G.729A/B, G.711µ/a-law, G.726, G.722(wide-band), G.723.1 ,iLBC, Opus,
      • in- band and out-of-band DTMF(in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC,
      • AGC, AJB
      • Telephony Features
      • Hold, transfer, forward, 5-way conference, call park, call pickup, downloadable
      • phonebook(XML, LDAP, up to 2000 items), call waiting, call log(up to 800 records),
      • off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot-desking,
      • personalized music ringtones and music on hold, server redundancy and fail-over
      • Auxiliary Ports RJ9 headset jack (allowing EHS with Plantronics & Jabra &Sennheiser headsets)
      • Base Stand Yes, 1 angle position available (45°), Wall Mountable (*wall mount sold separately)
      • QoS Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS
      • Security
      • Ordinary user and administrator level passwords based on SHA-256 and SHA-256
      • sess authentication, SIP authentication algorithms based on SHA-256, SHA-256
      • sess, SHA-512/256, SHA-512/256 sess, MD5 sess. AES security profile, SRTP, TLS call
      • encryption, 802.1X media access control.
      • Multi-language English, Chinese, Korean, Japanese, German, Italian, French, Spanish, Portuguese,
      • Russian, Croatian and more
      • Upgrade/Provisioning Firmware upgrade via FTP/TFTP / HTTP / HTTPS, mass provisioning using GDMS/TR069 or AES encrypted XML configuration file
      • Power & Green Energy Efficiency Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA;PoE:
      • IEEE802.3af Class 1, 3.84W; IEEE802.3az (EEE) (GRP2601P Only)
      • Temperature and Humidity
      • Operation: 0°C to 40°C
      • Storage: -10°C to 60°C
      • Humidity: 10% to 90% Non-condensing
      • Package Content GRP2601/2601P/2601W phone, handset with cord, base stand, universal power
      • supply (not included with GRP2601P), network cable, Quick Installation Guide
      • Physical Dimension: 208mm (L) x 180mm (W) x 63.4mm (H) (with handset)
      • Unit weight: 650g (651g for GRP2601W); Package weight: 810g (860g for GRP2601)
      • GRP2601/GRP2601P Compliance
      • FCC: Part 15 Class B; FCC Part 68 HAC;
      • CE: EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 62368-1;
      • RCM: AS/NZS CISPR32; AS/NZS 62368.1; AS/CA S004;
      • IC: ICES-003; CS-03;
      • GRP2601W Compliance
      • CE: EN 300 328; ETSI EN 301 489-1; ETSI EN 301 489-17; EN 55032; EN 55035; EN IEC
      • 61000-3-2; EN 61000-3-3; EN IEC 62368-1;EN IEC 62311.
      • UKCA: EN 300 328; ETSI EN 301 489-1; ETSI EN 301 489-17; BS EN 55032; BS EN
      • 55035; BS EN IEC 61000-3-2; BS EN 61000-3-3; BS EN IEC 62368-1;BS EN IEC 62311

Description

The GRP2601 features 5-way voice conferencing to maximize productivity, integrated PoE (GRP2601P), Wi-Fi support (GRP2601W), and is supported by Grand stream’s Device Management System (GDMS).

  • 2 SIP account, 2 lines
  • GDMS online device management and provisioning
  • 5-way audio conferencing for easy conference calls
  • Equipped with noise shield technology to minimize background noise
  • Electronic Hook Switch (EHS) support for Plantronics, Jabra, and Sennheiser headsets
  • The GRP2601P includes built-in PoE to power the device and give it a network connection
  • Enterprise-level protection including secure boot, dual firmware images and encrypted data storage
  • GRP2601W includes 2.4 GHz Wi-Fi support
